WIFI-104 4 in 1 Wifi Multi-zone Controller incl. RF remote control
DC 12V-24V (max 192W / 384W)
incl. RF radio remote control in safe 2.4GHz frequency range
WiFi reception radius up to 100m
Radio reception radius up to 30m
Manages up to 11 additional zones
1-channel, 2-channel, 3-channel or 4-channel operation can be configured per zone
Each zone is individually adjustable and dimmable
Several systems can be cascaded (SSID assignable)
All functions can be controlled via WiFi via the app "WIFI104"
For iOS and Android systems
RGB + W technology enables a selection of over 100 million colors
Matching CV radio receiver: R4-5A (constant voltage: LED Stripes, etc .)
Matching CC radio receiver: R4-CC (constant current: LED downlights, LED panels, etc.)
The WIFI-104 system is a new LED controlling system that can control up to 12 zones (rooms) individually via a WiFi interface. Up to 4 channels (RGBW) can be controlled per zone. Each zone can also be individually configured for 1-channel (dimmer), 2-channel (WW / CW) or 3-channel (RGB) operation. The connection to the optional R4 receiver is wireless, so there are no additional control cables to be laid. With the R4-CC receiver, constant current luminaires (eg LED downlights, LED panels, etc.) can also be controlled via the WIFI-104 system. In addition, the WIFI-104 controllerincluding RF remote control (2.4GHz range) shipped, so the system can be controlled at any time without existing WiFi connection. Several WIFI-104 systems can be cascaded. Thus, very extensive, completely wireless LED control systems can be realized.
The WIFI-104 can be described as absolutely multifunctional and unique. A WiFi LED control which can control both constant voltage and constant current LED light sources, to manage up to 12 zones, each with up to 4 channels and moreover can also be controlled by RF remote control, has not existed yet. A "Multiroom" controller system which is unparalleled in terms of performance.
The very extensive control app "WIFI-104" is available for free download and is available for iOS devices as well as for Android. The software can be found in the App Store or the Android version on Google play.
